TP057N

TNC-HCM2-A

Communication master for up to 28 AS-i controllers TNC-A1412 via Profibus DP

Without screen, external display via HTML5 (current browser)
Separate controller interface: Profibus DP gateway for a maximum of 28 ASi controllers TNC-A1412 or TNC-A1305/06
Factory installed TROXNETCOM Basic user software
Interface for connection to a building management system (BMS) via Ethernet with the protocols Modbus/TCP (server/slave) and BACnet/IP
For sending status messages of all dampers and smoke detectors to the building management system
Certified BACnet implementation (BTL)
BACnet configuration as EPICS and EDE files
USB-A port for data backups and software updates
24 V DC supply, 1.25 A
Remote diagnosis (TCP/IP) can be enabled
For installation in control cabinet with fixing bracket

Application

Application

External display with browser (HTML5):
Visualisation and operation via web server
Communication master for up to 28 AS-i controllers TNC-A1412 in the controller network Profibus DP
Modbus/TCP and BACnet/IP interface for connection to building management systems (BMS) without additional project planning effort
With pre-installed TROXNETCOM Basic user software

Order code

TNC-HCM2-A Communication master without screen; with separate Profibus DP gateway

Technical information

Diagonal size	7"
RAM	1 GB (4 GB max.) DDR3
Ethernet	2 × ETH, RJ45
Casing material	Metal
Connection	Push-in spring type terminal, 1.5 mm² max.
Installation	Horizontal
IEC protection class	Front: IP 64 Back: IP 20
Certification	CE, RoHS
Power consumption	24 V DC, operation: ≤ 500 mA, power on: ≤ 1.25 A
Operating temperature range	0 °C – +50 °C
Communication interfaces	2 × Ethernet, RJ45, 2 × USB-A
Video interfaces	1 × micro HDMI
Switches and LEDs	5 × diagnosis LEDs

Specification text

Communication master for visualisation and operation via web server. Communication master for up to 28 AS-i controllers TNC-A1412 in the controller network Profibus DP.

Without screen
Communication master for controller network Profibus DP in connection with TNC-DP Master for up to 28 AS-i controllers TNC-A1412
Interfaces: Modbus/TCP and BACnet/IP for connection to a building management system (BMS) without additional project planning effort
With pre-installed TROXNETCOM Basic user software for control and display of the system statuses
Automatic functional test, including documentation
Real time clock
Ethernet, USB
Protection level: IP 20
Supply voltage: 24 V DC
Make: TROX GmbH or equivalent
Type: TNC-HCM2-A

Downloads

product information

TROXNETCOM AS-i Master and display units

K 4 – 6.2 – 21 Technical Leaflet 540 KB pdf
