AS-i Safety input module for capturing an actuator end position, approved for applications up to SIL2 to IEC/EN 61508

The module is used to connect the control system with the components

  • Integral AS-Interface slave
  • Monitoring of signal receipt
  • With short circuit protection
  • Easy wiring due to flat cable insulation displacement connectors ('click and go')
  • Certified motor control modules for safe communication up to SIL2
  • Special modules for dampers with special functions including redundant voltage supply
  • Universal module for the connection of various terminal units such as fire dampers, smoke protection dampers or duct smoke detectors

Application

Application

  • AS-i Safety input module for capturing the actuator end positions
  • Approved for applications up to SIL 2 according to IEC/EN 61508
  • Supplied either mounted on the damper blade and wired to the actuator or as a separate unit
  • Integral AS-Interface slave
  • Monitoring of signal receipt
  • Supply voltage to the module through the AS interface

Technical information

  • Technology
  • Specification text
  • Order code

DescriptionTNC-A005S
Electrical design2 inputs
Supply voltage26.5 – 31.6 V DC
Current consumptionType 80, max. 200 mA depending on sensor
Control category to EN 954-14
AS-i specificationV2.1
AS-i profileS-7.B.1
Short circuit monitoringYes
EMCEN 50081-1; EN 50082-2
Protection levelIP 67
Ambient temperature–20 to 60 °C
Display of AS-i voltageLED green
Display of inputLED yellow
AddressingWith addressing socket
Casing dimensions H × B × T80 × 45 × 24 mm
FixingOn mounting rail


Standard description (characteristics)

  • AS-i Safety input module for capturing an actuator end position
  • Approved for applications up to SIL 2 according to IEC/EN 61508
  • Supplied mounted on the damper blade and wired to the actuator
  • Integral AS-Interface slave
  • Monitoring of signal receipt
  • Connection with flat cable insulation displacement connector
  • Supply voltage to the module through the AS interface
  • Total current consumption from AS-i: ≤ 800 mA
  • Ambient temperature: –20 to 60 °C
  • Protection level: IP 65
  • Make: TROX GmbH or equivalent
  • Type: TNC-A005S

00135241_0


 Module
AS-EPR       Module for the connection of four limit switches
AS-EM       Module for controlling an actuator
AS-EM/EK       Module for controlling actuators on smoke control dampers
AS-EM/SO       Module for controlling actuators with special functions
AS-EM/SIL2       Module for controlling actuators with SIL2 certificate
AS-EM/C       Module for universal control functions, 2 outputs, 4 inputs
TNC-A005S       AS-i safety input module
TNC-Z0094       Relay module 4E/4A
TNC-Z0047       Illuminated push button module



Downloads

operation manuals

  • System manual TROXNETCOM AS-i System manual version 3.0

    AS-i_SH_2021_11_A00000079151_V3_GB_en System manual  13 MB pdf
